1

  • Dimension (H x W x D): 365 x 170 x 350 mm
  • Motherboard Support: Micro ATX, Mini ITX
  • I/O Port: USB x 2, HD Audio x1
  • Drive Bays: 5.25” ODD x 1, 3.5” HDD x 1, 2.5” SSD x 3
  • Fan Support (Optional): Front : 2 x 120 mm, Rear : 1 x 80 mm, Side : 1 x 120 mm

2

3

SPECIFICATION
Case Type Mini Tower
Motherboard Support ATX, Micro-ATX
Color Black
Expansion Slots 4
Material SPCC & ABS
Window N/A
Radiator Support N/A
Fan Support Front: 2 x 120mm
Rear: 1 x 80mm
Side 1 x 120mm
Pre-installed Fans N/A
Drive Bays 1 x 5.25"
2 x 3.5"
2 x 2.5"
I/O Port USB x2, HD Audio x1
PSU Top, Standard ATX PSU
Clearance CPU cooler height limitation: 15mm
VGA length limitation: 300mm
PSU length limitation: 170mm
Dimension (H x W x D) 365 x 170 x 386 mm
Net Weight TBD
